TD-4100N
Desktop Bar Code Network Printer
Windows® GDI technology revolutionized how we view and use software today, so why limit how you print your labels, receipts and tags with legacy printer restrictions?
The TD-4100N desktop bar code printer is a true GDI network printer, fully compatible with Windows® OS computers – including Windows® 7¹. The TD-4100N will print on most medium/high sensitivity direct thermal media in high quality 300 dots/inch print resolution, and comes ready with everything you need to start printing including the USB cable and PT-Editor, powerful but easy to use design software application.
Use PT-Editor to add bar codes, lines, curves, text and graphics, and print by typing in your data or link to a Microsoft® Excel® or Access® database file or SQL server and select one or multiple records. Or, use your own Windows®-based software application as the TD-4100N comes with a WHQL certified Windows®-based printer driver and is compatible with many third party Windows®-based software applications.
Unlike competitive models that require printing using their resident fonts and bar codes, the TD-4100N is host-based and can print text, bar codes and graphics from software, up to 4.3 inches/second. The built-in automatic cutter reliably trims receipts and continuous labels to your desirable length, or configure it to cut after printing die cut labels – either one at a time or after printing a strip of multiple labels.
The TD-4100N is built around a mechanism with a history of reliability and comes with a 1 year limited warranty and toll free customer support. With this combination of high performance, value add and reliability, why not experience this for yourself and see why the TD-4100N is the best value desktop bar code printer for your Windows®-based application.
Main Features
- High performance, 4” wide desktop bar code printer
- Uses Genuine Brother or most medium/high sensitivity direct thermal label, receipt and tag media
- Fully compatible with Windows® OS computers, including Windows® 7¹
- Bundled with PT-Editor print application design software
- Prints high quality 300 dpi text, graphics and bar codes
- Fast, host based printing – up to 4.3 ips
- Reliable built-in automatic cutter
- 10/100 Base TX Ethernet, USB 2.0 and RS-232C serial interface connectivity
Brother TD-4100N label printer Direct thermal 300 x 300 DPI 110 mm/sec
SKU: TD4100NZU1£168.00 ex VAT
£201.60 inc VAT
Print quality Vertical printing Yes Maximum resolution 300 x 300 DPI Printing Vertical printing Yes Print speed 92 lpm Print speed 110 mm/sec Maximum resolution 300 x 300 DPI Print technology Direct thermal Network Network ready Yes Memory Internal memory 2 MB Paper handling Media thickness 0.076 - 0.153/0.178 mm Maximum roll diameter 10.2 cm Maximum label width 10.2 cm Maximum label length 3 m Ports & interfaces Standard interfaces USB 2.0, Ethernet PC connected Yes Performance Number of styles 7 Built-in barcodes Codabar (NW-7), EAN13, EAN8, Maxicode, Postnet, QR Code, UPC-A, UPC-E Number of fonts 5 Tape cutting Automatic Internal memory 2 MB Design Product colour Grey Built-in display No Weight & dimensions Dimensions (WxDxH) 173 x 229 x 158 mm Width 104 mm Depth 253 mm Height 310 mm Weight 2.43 kg Package weight 2.9 kg Power Power requirements 220-240VAC, 50/60 Hz, 1.8A Technical details Product colour Grey Label type RD Number of styles 7 Built-in barcodes Codabar (NW-7), EAN13, EAN8, Maxicode, Postnet, QR Code, UPC-A, UPC-E Number of fonts 5 Tape cutting Automatic Maximum label width 10.2 cm Maximum label length 3 m Country of origin China Products per pallet 54 pc(s) Layers per pallet 6 pc(s) Master (outer) cases per pallet 18 pc(s) Harmonized System (HS) code 84433210 Pallet type 800 x 1200 mm Software Bundled software P-touch PT-Editor 5.0, Transfer Manager 2.1, Transfer Express, Library 2.1 System requirements Mac compatibility No Minimum RAM 128 MB Minimum storage drive space 70 MB Compatible operating systems Windows XP/7, Windows Vista, Windows Server 2003/2008 Operational conditions Operating temperature (T-T) 10 - 35 °C Operating relative humidity (H-H) 20 - 80% Packaging data Package weight 2.9 kg Package dimensions (WxDxH) 360 x 229 x 248 mm Packaging content Bundled software P-touch PT-Editor 5.0, Transfer Manager 2.1, Transfer Express, Library 2.1 Other features Products per pallet 54 pc(s) Layers per pallet 6 pc(s) Master (outer) cases per pallet 18 pc(s) Label type RD Network ready Yes Dimensions (WxDxH) 173 x 229 x 158 mm Country of origin China Logistics data Pallet gross height 17.3 cm Master (outer) cases per pallet layer 3 pc(s) Pallet gross weight 183.6 kg Products per pallet 54 pc(s) Layers per pallet 6 pc(s) Master (outer) cases per pallet 18 pc(s) Harmonized System (HS) code 84433210 Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
Items must be returned in an unused and saleable condition within 16 days of the receipt of goods. Please read our delivery and returns policy for further information.
